| Name | Value |
| Package | SFP28 LAN-WDM |
| Data Rate | 25Gbit/s |
| Wavelength | 1273.54~1309.14nm |
| Connector | Duplex LC |
| Reach | 40km |
| Temp | 0-70 |
| DDM | YES |
| Fiber Type | SMF |
SLSLD-25XX-ER SFP8 transceivers are high performance, cost effective modules supporting data rate of 25.78Gbps and 40km transmission distance with SMF.
The transceiver consists of three sections: an EML laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
| Package (Form Factor) | SFP28 LAN-WDM |
| Data Rate (typical) | 25.78Gb/s |
| Centre Wavelength | 1273.54nm~1309.14nm |
| Distance | 40km |
| Diagnostics | Digital Monitor |
| Transmitter | CWDM DFB Laser |
| Receiver | PIN photo detector |
| TX Output Power (dBm) | 0~+6 |
| RX Sensitivity (dBm) | <-19 |
| Low/High Case Temperature | 0°C~70°C |
| Voltage Supply (typical) | 3.3v |
| Connector | Duplex LC/UPC |
