16G CWDM SFP+ 1470~1610NM 40KM
16G CWDM SFP+ 1470~1610NM 40KM
型号 : SLSSC-16XX-40
咨询
Name Value Package CWDM SFP+ Data Rate 16Gbit/s Wavelength 1470~1610nm Connector Duplex LC Reach 40km Temp 0-70 DDM YES Fiber Type SMF
Sourcelight 16Gbps SFP+ CWDM 40km transceivers, according to 16 Gigabit Small Form Factor Pluggable “SFP+” Multi-Sourcing Agreement (MSA) SFF-8431 Rev. 3.0 and SFF-8472 Rev. 11.0, are designed for use in Fibre Channel links up to 14.025Gb/s data rate and up to 20km link length, They are compatible with FC-PI-5 Rev. 6.10.
Electrical interface specifications per SFF-8431
Management interface specifications per SFF-8431 and SFF-8472
SFP+ MSA package with duplex LC connector
CWDM EML Transmitter
Up to 14.025Gb/s bi-directional data links
Build-in dual CDR at 14.025CDR and Bypass at 4.25Gb/s and 8.5Gb/s
100GHz ITU Grid, C-Band
Single +3.3V power supply
Class 1 laser safety certified
Commercial operating temperature: 0ºC ~ +70ºC
Up to 40km on 9/125µm SMF
RoHS Compliant
Package (Form Factor)
16G SFP+
Data Rate (typical)
14.025 Gb/s
Centre Wavelength
1470~1610nm
Distance
40km
Diagnostics
Digital Monitor
Transmitter
CWDM EML Laser
Receiver
PIN photo detector
TX Output Power (dBm)
-1~+3
RX Sensitivity (dBm)
-14
Low/High Case Temperature
0°C~70°C
Voltage Supply (typical)
3.3v
Connector
Duplex LC/UPC
Tri Rate 4.25 / 8.5 / 14.025 Gb/s Fibre Channel through Rate 10G Fiber Channel
